ES-80 Shaker-incubator
.jpg)
Stable and reliable orbital shaker-incubator for vigorous or even mixing and incubation of samples in a variety of flasks and vessels.
- Digital control of time, temperature and shaking speed for accuracy and repeatability
- Variable speed: 50 to 250 rpm
- Temperature range: 25 to 80°C
- Load up to 8 kg
- Interchangeable platforms for shaking/incubating different vessels
- Temperature control by microprocessor plus forced heated air circulation ensure a constant and even temperature within the chamber
- Robust, compact construction with stainless steel inside chamber
- Equipped with direct drive shaking system for reliable, long-term operation
- Simple to programme time, - 1 minute to 96 hours or non-stop
- State-of the art motor, thermal insulation materials and temperature PID-control decreses the energy consumption
| Shaking incubators - specification | |||
|---|---|---|---|
| ES-20 | ES-80 | ||
| Speed range | rpm | 50 to 250 | |
| Orbit | mm | 10 | 20 |
| Temperature setting range | °C | 25 to 42 | 25 to 80 |
| Temperature control range | °C | +5 above ambient to 42 | +10 above ambient to 80 |
| Temperature setting resolution | 0.1°C/1rpm | 0.1°C | |
| Timer | 1 min to 96 hours | ||
| Continuous operation | hrs | 96 | 168 |
| Load capacity | kg | 2.5 | 8 |
| Display | 2 line 16 character LCD | ||
| Internal working height | mm | 270 | |
| Overall dimensions | w x l x h mm | 340 x 340 x 435 | 590x525x510 |
| Weight | kg | 15 | 43 |
| Power supply | V | 230 (50-60 Hz) | |
| PP-400 Flat platform with non-slip rubber mat (360 x 400mm) |
 |
| P30-100 Platform with clamps for 30 x 100 ml flasks |
|
| P16-250 Platform with clamps for 16 x 250 ml flasks |
|
| P9-500 Platform with clamps for 9 x 500 ml flasks |
|
| P6-1000 Platform with clamps for 6 x 1000 ml flasks ml |
|
